What Is An Intelligent Electric Ball Valve?

Intelligent electric ball valves are a large category. Generally speaking, as long as the electric actuator is intelligent, it is often called an intelligent electric ball valve. The term "intelligent" also means that intelligence is in the electric actuator. The ball valve itself is only used as a switch, but there are many types of ball valves, all of which can be used. Install electric actuators, and there are many types of intelligent electric actuators. Commonly used ones include intelligent explosion-proof type, intelligent switch type, intelligent adjustment type, intelligent explosion-proof adjustment type, etc. The advantage of the explosion-proof intelligent electric ball valve is that it can be started and closed, started and stopped by buttons on the spot, or controlled from a distance of 10 meters through a remote control, reducing the danger of high-altitude operations and close operations in harsh working conditions. The explosion-proof intelligent electric ball valve also has remote control. The intelligent actuator has an LCD display value. The internal working principle also realizes high adjustment, opening and closing through digital operations. Therefore, this type of explosion-proof intelligent electric ball valve is particularly suitable for use in remote automated fluid control systems. used as a shutdown, switch, and regulating medium.

Intelligent electric ball valve-explosion-proof intelligent regulating actuator introduction:

The intelligent electric actuator is a new type of intelligent integrated electric actuator with automatic debugging, fault self-diagnosis and self-processing functions. It can directly accept the 4-20mAd.c. control signal from the computer, regulator or operator. Taichen brand explosion-proof intelligent electric ball valve actuator uses electricity as the driving energy and has a built-in servo system. No additional servo amplifier is required. The operation can be controlled by inputting 4-20mA or 0-10V. Explosion-proof intelligent adjustable electric actuators can be configured into UNIC, PSQ, HQ, QT, LQ, DHL and other series products according to user requirements.

Features of explosion-proof intelligent electric regulating actuator:

1. The reducer adopts a two-level precision worm gear transmission mechanism, which has the characteristics of low noise, high efficiency, self-locking, etc.; the hand-operated mechanism has an automatic reset function when power is turned on; the whole machine has reliable three protections of overheating, overload and limit. , which can ensure the safe operation of the product.

2. The protective performance of the shell reaches IEC IP67, NEMA 4 and 6 standards, and has excellent outdoor performance.

3. It has two series and proportional series according to the combination method, and has EXd II BT4 explosion-proof level, which can meet the needs of various types of angle-turn control valves. It is a high-quality choice for domestic electric actuators with high performance and low price.
